High precision UMot 120mm width worm drive linear guide set rail module actuator for diy cnc machine in Linear Guides from Home Improvement

High precision UMot 120mm width worm drive linear guide set rail module actuator for diy cnc machine in Linear Guides from Home Improvement
High precision UMot 120mm width worm drive linear guide set rail module actuator for diy cnc machine in Linear Guides from Home Improvement
High precision UMot 120mm width worm drive linear guide set rail module actuator for diy cnc machine in Linear Guides from Home Improvement
High precision UMot 120mm width worm drive linear guide set rail module actuator for diy cnc machine in Linear Guides from Home Improvement
High precision UMot 120mm width worm drive linear guide set rail module actuator for diy cnc machine in Linear Guides from Home Improvement
High precision UMot 120mm width worm drive linear guide set rail module actuator for diy cnc machine in Linear Guides from Home Improvement

Product Specification

Guide Width or Diameter: 120mm

Model Number: SW120

Brand: UMot

Effective Stroke: 100-500mm

Position Accuracy: 0.05mm

Screw Precision Grade: C7

Screw Type: 2020

Stepper Motor Type: 86-128

Stepper Motor Driver: as to your requirements

Controller: as to your requirements

Limit switch: 2 for free

Applicable industry: Handling conveyor/Laser welding measuring/CNC machine tool

Application field: Automatic welding series/Board processing/Filming equipment

Description:
High precision UMot 120mm width worm drive linear guide set rail module actuator for slide door diy cnc machine

UMot stable single-axis ball screw driven linear axis is customized product. The max travel length we can do is from 50mm to 3000mm.The length that is not in the option can be customized by contacting customer service. Please contact us to customize your linear guide rails.

Discount will be given to you if you leave a message to us.

Brand:UMot
Material:Bearing steel
Length customization:50-3000mm(standard length, support customization)
Position Accuracy:0.05mm
Screw Precision Grade:C7
Screw Type:2020
Stepper Motor Type:86-128
Stepper Motor Driver:as to your requirements
Stepper Motor Controller:as to your requirements
Limit switch:2 for free
Application field:Automatic welding series/Board processing/Filming equipment
Applicable industry:CNC machine,laser equipment,packaging equipment,textile equipment,medical equipment,electronic equipment,advertising equipment,3d printer,machine equipment,security monitoring,new energy,building automation,robot system,Laser Marking Machines,Laser Engraving Machines,Laser Beauty Equipment,Wood Router,Woodworking machinery,laser cutting engraving etc.





120---2020_03120---2020_04120---2020_05120---2020_06120---2020_07120---2020_08120---2020_09120---2020_10120---2020_11 120---2020_14120---2020_15120---2020_16

80_20





80_1

80_19
